W+D 202 stack printer, Reference 3906

Description
Stack-type web printing stand with 5 doctor blade flexo printing units
Model
W+D 202 stack printer
Year
2001
Envelope Type
Working From
Printing unit
Window
No
Printing
6 color
Technical Data

minimum paper width:     145 mm

maximum paper width:     390 mm

maximum printing width:  380 mm

minimum diameter of printing cylinder 68 mm

maximum diameter of printing cylinder 134 mm



paper weights: from 60 g/m² up to 120 g/m²

Configuration
  • Can be integrated with W+D 202, 627 and 527 machines (servo or conventional drive systems)
  • Can be up-graded with a 6th printing unit
Machine Condition
Good condition
